| Model parameters; | |
| Work schedule (xyz) | 300×300×100mm |
| Carving depth; | 150mm |
| Maximum carving speed& nbsp; | 3000mm/min |
| Processing accuracy& nbsp; | Less than 0.05/300mm; |
| Carving instructions& nbsp; | G code |
| Spindle & nbsp; | 3.0kw water-cooled spindle |
| Tool diameter& nbsp; | Φ3.175，Φ6 |
| Xyz guide rail& nbsp; | squarelinear guide rail |
| Transmission mode& nbsp; | XY high-precision gear rack and pinion; |
| Z-axis ball screw transmission; | |
The bed is made of thick walled steel pipes welded together and subjected to high-temperature tempering treatment to ensure minimal deformation, good rigidity, and high strength of the machine body& nbsp;
The Y-axis is driven by dual motors and carefully paired to ensure smooth movement& nbsp;
Adopting high-precision gear rack transmission, high precision, fast speed, and strong force& nbsp;
Adopting imported square linear guide rails, with high precision, large load-bearing redundancy, and long service life& nbsp;
Fully optimized electromechanical design, selecting various electrical accessories to minimize the failure rate& nbsp;
The machine tool is equipped with a sink and a self-service water supply cooling system& nbsp;
Dustproof and waterproof design, providing comprehensive protection for machine transmission components& nbsp;
The Y-axis is driven by dual motors and carefully paired to ensure smooth movement& nbsp;
Adopting high-precision gear rack transmission, high precision, fast speed, and strong force& nbsp;
Adopting imported square linear guide rails, with high precision, large load-bearing redundancy, and long service life& nbsp;
Fully optimized electromechanical design, selecting various electrical accessories to minimize the failure rate& nbsp;
The machine tool is equipped with a sink and a self-service water supply cooling system& nbsp;
Dustproof and waterproof design, providing comprehensive protection for machine transmission components& nbsp;
Application scope: 3D relief and line carving, cutting, chamfering, drilling 2D carving of natural marble, granite, artificial stone, tombstones, milestones, ceramic tiles, glass and other materials.
Monthly production of over 1000 units.
Our professional sales and after-sales service team will promptly and efficiently solve your problems.
